The LatticeSC/M (System Chip/MACO) family of FPGAs combines a high-performance FPGA fabric, 3.8Gbps SERDES and PCS, 2Gbps Parallel I/Os, low-power 1V Vcc option, large embedded RAM, and embedded ASIC blocks to provide the highest performing FPGA in the industry.
Designed with the needs of today's high-speed connectivity-based systems in mind, LatticeSC family delivers best in class solutions for high throughput standards like Ethernet, PCI Express, SPI4.2 and high speed Memory Controllers. LatticeSC is equipped with embedded memory, hierarchical clocking and clock management resources for high-end system designs. For low-cost, system-level integration, the LatticeSCM family offers MACO (Masked Array for Cost Optimization): up to 12 embedded structured ASIC blocks per device with a variety of pre-engineered IP blocks.
Key Features
- High Performance FPGA Fabric
- 15K to 115K Four Input Look-up Tables (LUT4s)
- 139 to 942 I/Os
- 700MHz global clock; 1GHz edge clocks
- Design for Low Power: 1V Vcc Option Reduces Fabric Power Consumption By 44%
- High Speed SERDES: 4 to 32 SERDES per device @ 600Mbps to 3.8Gbps featuring:
- Pre-emphasis and equalization
- Low power (105mW per channel)
- Embedded Physical Coding Sublayer (PCS) supports: PCI Express GbE, XAUI, SONET, 1G Fibre Channel, 2G Fibre Channel and Serial Rapid IO
- PURESPEED Technology: 2Gbps Parallel I/O
- Input Delay (INDEL) with Adaptive Input Logic (AIL) dynamically aligns data on a per-pin basis for robust high performance source synchronous I/O support
- Supports generic DDR up to 2Gbps; generic SDR up to 1Gbps; Single-ended memory interfaces up to 800Mbps
- Comprehensive standards support: LVCMOS; LVTTL; PCI, PCI-X; LVDS, Bus-LVDS, MLVDS, LVPECL; with programmable On Device Termination (ODT) options
- MACO: On-Chip Structured ASIC Blocks provide pre-engineered IP at lower power and cost
- Pre-engineered IP for low cost, low power, system level integration
- Memory Intensive FPGA
- 1 to 7.8 Mbits Embedded Block RAM @ 500MHz
- Additional distributed RAM: 240K to 1.8Mbits
- sysCLOCK PLLs and DLLs
- Eight PLLs per device running up to 1GHz
- Spread Spectrum support on PLLs
- 12 DLLs per device running up to 700MHz
- System Level Support
- IEEE Standard 1149.1 Boundary Scan
- IEEE Standard 1532 In-System Configuration
- Embedded PowerPC microprocessor interface
- Embedded System Bus
LatticeSC and LatticeSCM FPGA Family Selector
| Parameter |
LFSC15 |
LFSC25 |
LFSC40 |
LFSC80 |
LFSC115 |
| Logic Resources – LUTs (K) |
15.2 |
25.4 |
40.4 |
80.1 |
115.2 |
| sysMEM EBR RAM Blocks (18Kb / Block) |
56 |
104 |
216 |
308 |
424 |
| Embedded Memory (Mbits) |
1.03 |
1.92 |
3.98 |
5.68 |
7.80 |
| Max. Distributed Memory (Mbits) |
0.24 |
0.41 |
0.65 |
1.28 |
1.84 |
| Max. # of SERDES Channels (3.8Gbps) |
8 |
16 |
16 |
32 |
32 |
| DLLs |
12 |
12 |
12 |
12 |
12 |
| PLLs |
8 |
8 |
8 |
8 |
8 |
MACO Blocks (LatticeSCM only)
|
4 |
6 |
10 |
10 |
12 |
| Packages |
I/O / SERDES Count |
| 256-ball fpBGA (17 x 17 mm) |
139 / 4  |
|
|
|
|
| 900-ball fpBGA (31 x 31 mm) |
300 / 8 |
378 / 8 |
|
|
|
| 1020-ball fcBGA (33 x 33 mm) |
|
476 / 16 |
562 / 16 |
|
|
| 1152-ball fcBGA (35 x 35 mm) |
|
|
604 / 16 |
660 / 16 |
660 / 16 |
| 1704-ball fcBGA (42.5 x 42.5 mm) |
|
|
|
904 / 32 |
942 / 32 |
LatticeSC Evaluation Boards
Lattice has developed three platforms for evaluating the features and performance of the LatticeSC FPGA.
LatticeSC Communications Board: This board is an advanced communications platform that will help you explore how the LatticeSC performs to a variety of communications standards and specifications. Features of this board include a 300-pin MSA transponder interconnection to evaluation Single Data Rate (SDR) performance for SFI-4.1/XSBI applications, a Molex VHDM interconnection to system packet interface level 4-phase 2 (SPI-4.2), a 200-pin SODIMM socket supporting 64-bit 200-pin DDR-2 SDRAM, numerous SMA test points for high-speed SERDES and Clock I/O, and much more.
LatticeSC PCI Express x8 Evaluation Board: This board will help you evaluate the performance of the LatticeSC in additional application spaces. Key features of this board include a x8 PCIexpress edge connector / form-factor, on-board DDR2 Memory, BNC edge connectors for Digital Video Interface, SMA connectors for SERDES I/O, LVDS evaluation, and external clock I/O, and more.
LatticeSC PCI Express x1 Evaluation Board: Key features of this board include a x1 PCIexpress edge connector / form-factor, On-board QDR2 and RLDRAM2 Memory, SATA Host/Target, 1Gbe SFP, SMA connectors for SERDES I/O, LVDS evaluation, and external clock I/O, Tri-speed Ethernet PHY with RJ45 jack, RS-232 port, and more. |
The LatticeSC should finally silence the skeptics: this is a very high performance FPGA that will compete aggressively with Virtex and Stratix devices for sockets. With the simultaneous announcement of the low cost LatticeECP2 devices, Lattice now has the breadth and depth of FPGA products to become the third force in the FPGA market.
Gerald S. (Jerry) Worchel, Principal Analyst, In-Stat's Semiconductor Logic Service
|
